Precision Solid-State Mems Gyro Continuous Inclinometer for Accurate Physical Measurements
Product ID: SMTJZ2
Send Inquiry
1. Ground measurement and control instrumen
1) Input voltage: AC 90V~250V, 50Hz~60Hz;
2) Output voltage: DC 0V~200V;
3) Output load capacity: 0A~1A adjustable;
4) Full load range output ripple: ≤0.5%;
5) Working environment temperature: -40ºF~+185ºF;
6) Signal code: Manchester code;
7) Communication interface: USB 3.0 and below interface;
8) Other specifications:
The box is easy to carry;
with current, voltage display and adjustment;
It has a depth encoder access interface and has a deep analysis function.
2. Measurement and control software
1) Operating environment: WINDOWS10 and below;
2) Data output: three figures and one table (stereoscopic trajectory map, projection map, top view, data table);
3) Functional requirements: the measurement and control software needs to display the logging data in real time during the logging process, such as oblique, azimuth, depth, high side, etc.; For orientation testing, real-time angle test function is available.
1) Input voltage: AC 90V~250V, 50Hz~60Hz;
2) Output voltage: DC 0V~200V;
3) Output load capacity: 0A~1A adjustable;
4) Full load range output ripple: ≤0.5%;
5) Working environment temperature: -40ºF~+185ºF;
6) Signal code: Manchester code;
7) Communication interface: USB 3.0 and below interface;
8) Other specifications:
The box is easy to carry;
with current, voltage display and adjustment;
It has a depth encoder access interface and has a deep analysis function.
2. Measurement and control software
1) Operating environment: WINDOWS10 and below;
2) Data output: three figures and one table (stereoscopic trajectory map, projection map, top view, data table);
3) Functional requirements: the measurement and control software needs to display the logging data in real time during the logging process, such as oblique, azimuth, depth, high side, etc.; For orientation testing, real-time angle test function is available.
