Feature:
1.    Whole machine is welded with seamless steel structure,the stability is excellent, not easy to be deformed.
2.   Adopt 2.2KW China domestic made water cooling spindle.
3.    The machine adopts gantry movement,it can process any kinds of materials freely.
4.    Three axes adopt imported ball screw and circle orbit,stable working,high precision and long life time.
5.    X axis is dustproof.It makes sure the steady working performance of the machine for long-term using.
6.    Well compatibility:CAD/CAM designing software, e.g.
Type3/Artcam/Castmate/Wentai etc.
7.    Has the function of forecasting process time.
8.    High precision,the curving and linear speeds are consistent.Adopting excellent parts makes the fault rate to be the lowest one.
Technical Parameter:
Model PC-1218 PC-1318 It can be customized
X.Y working area（mm） 1200*1800 1300*1800
Z working area 80mm
Table size 1400mm*2000mm
Resolution 0.01mm
X,Y structure Imported ball screw
Z structure Imported ball screw
Max speed 12m/min
Spindle power 1.5KW/2.2KW/3.0KW
Spindle rotating speed 0-24000r/min
Cooling mode Water cooling
Working voltage AC220V/50/60 Hz ,2PH
Drive Motor Stepper
Command G code*.u00*.mmg*plt
Operating system NC Studio
Diameter of cutter 3.175-8
Work-holding By clamp
Applicable industries:
Wood processing:processing of various furniture such as door,window,cabinet,craft wood door,screen and so on.
Advertisement:engraving and cutting various labels and number plate.
Art craft:engraving characters of any languages and graphics on gifts and souvenirs.
Applicable materials:
Wood,aluminum board,plastic,density board,wave board,PVC,acrylic,crystal,light marble and other nonmetal materials and light metal materials.
